SCRAM 440, BORN FROM ADVENTURE

Table of Contents

ENGINE DETAILS TUNED FOR PLAY.

The Scram 440 has a six-speed gearbox and a sophisticated Long Stroke 443 cc engine (LS 440). The Scram guarantees that you can transform commonplace objects and obstacles into exciting adventures with its maximum torque of 34 nm and maximum power of 25.4 Bhp, improved NVH levels, and enhanced performance throughout the rev range.

Displacement 443 cc

Max Power 25.4 bhp @ 6250 rpm

Max Torque 34 Nm @ 4000 rpm

Top Speed 120 kmph

Mileage Owner Reported

30 kmpl

Transmission 6 Speed Manual

Transmission Type Chain Drive

Gear Shifting Pattern 1 Down 5 Up

Clutch Wet Multiplate

Riding Range 450 km

Riding Modes No

Cylinders 1

Valves Per Cylinder 2

Cooling System Air Cooled

Bore 81 mm

Stroke 86 mm

Compression Ratio 9.5:1

Spark Plugs 1 Per Cylinder

Battery 12 V , 8 Ah Maintenance Free

Emission Standard BS6 Phase 2

Fuel Type Petrol

COLOURS .

BRAKES & TYRES

Dual-purpose 19/17-inch tough alloy wheels allow you to create your own track and offer confident handling on any surface. Shorter stopping distances and enhanced feel, bite, and power are features of the most recent generation’s improved braking.

Braking System

Switchable ABS.

Front Brake Type Disc.

Front Brake Size 300 mm.

Caliper – Front

2 Piston.

Rear Brake Type

Disc.

Rear Brake Size

240 mm.

Caliper – Rear

1 Piston.

Wheel Type

Spoke.

Front Wheel Size

19 inch.

Rear Wheel Size

17 inch.

Front Tyre Size

100/90 – 19.

Rear Tyre Size

120/90 – 17.

Tyre Type

Tubed.

Front Tyre Pressure (Rider)

25 psi.

Rear Tyre Pressure (Rider)
32 psi.
Front Tyre Pressure (Rider & Pillion)
27 psi.
Rear Tyre Pressure (Rider & Pillion)
34 psi.

Suspensions & Chassis

Front Suspension

Telescopic, 41mm forks.

Rear Suspension

Monoshock with linkage.

Front Suspension Preload Adjuster.

Rear Suspension Preload Adjuster.

Yes.

Chassis Type

Half-Duplex Split Cradle Frame.

Dimensions

Kerb Weight

196 kg.

Seat Height

795 mm.

- Seat Length.
  –

Ground Clearance

200 mm.

Fuel Tank Capacity

15 litres.

Reserve Fuel Capacity

3 litres.

Overall Length

2165 mm.

Overall Width

840 mm.

Overall Height

1170 mm.

Wheelbase

1460 mm.

Manufacturer Warranty

Standard Warranty
3 year.
Standard Warranty
30000 km.

Service & Maintenance Schedule.
1st Service
500 Kms/45 Days.
2nd Service
5000 Kms/180 Days.
3rd Service
10000 Kms/365 Days.
4th Service
15000 Kms.

Features

Instrument Cluster
Instrument Console
Semi-Digital.
Touch Screen Display
No.
- - Brightness Control-
    Yes.
Mobile Phone Connectivity-
No.
GPS & Navigation-
No.
Speedometer
Analogue.

Odometer
Digital.

Fuel Gauge
Digital.

Tripmeter Type
Digital.

No. of Tripmeters
2.

Tachometer
No.

Stand Alarm
Yes.
Low Battery Indicator
Yes.
Low Fuel Indicator
Yes.
Gear Indicator
Yes.
Voice Assist
No.
Low Oil Indicator
No
Service Reminder Indicator
Yes
Hazard Warning Indicator
Yes
High Beam Indicator
Yes
Engine Temperature Indicator
No
Malfunction Indicator
Yes
Average Speed
–
OTA Updates
Not Available
Call/SMS Alerts
No
Clock
Yes
Collapse
Thank you for your feedback.

Safety & Convenience
USB Charging Port
Yes.
Keyless Lock/Unlock
No.
Saree Guard

Yes.
Quickshifter

No.
Mobile App Monitoring.
Vehicle Location Tracking.

No.
Geo Fencing
No.
Lights.
Headlight Type
LED.
Projector Headlamp
No.
Dual Lights
No.
DRLs (Daytime Running Lights)
Yes.
Seat & Storage
Under Seat Storage
No
Pillion Seat
Yes
Pillion Backrest
No
Pillion Footrest
Yes
